LPH-18-TFS - Mean Well LPH-18 Series Double Insulated Mains Input LED Driver 18W - 20W 12V – 36V
Constant VoltageFully encapsulated with IP67 levelProtections: Short circuit/ Overload/ Over voltage/ Over temperatureOther features: 180~264VACClass 2 power unitIsolation class II, no F.G.Cooling by free air convectionPass LPS100% full load burn-in testLow cost, High reliability2 years warranty
More Information Manufacturer Mean Well Output Wattage (W) 18 Dimmable (Type) No Dimensions 140 x 30 x 20 (LxWxH) Mm EMC Standards EN55022 class B, EN61000-3-2 class A, EN61000-3-3, EN61000-4-2, 3, 4, 5, 6, 8, 11 Input Voltage 180~264VAC Safety Standards TUV EN60950-1 approved, Design refer to UL1310, EN61347-2-13 Output Voltage Options Single Working Temperature -20~+70°C PDF Datasheet LPH-18TF_Series.pdf
More Information Manufacturer Mean Well Output Wattage (W) 18 Dimmable (Type) No Dimensions 140 x 30 x 20 (LxWxH) Mm EMC Standards EN55022 class B, EN61000-3-2 class A, EN61000-3-3, EN61000-4-2, 3, 4, 5, 6, 8, 11 Input Voltage 180~264VAC Safety Standards TUV EN60950-1 approved, Design refer to UL1310, EN61347-2-13 Output Voltage Options Single Working Temperature -20~+70°C PDF Datasheet LPH-18TF_Series.pdf
Product Information
Product Information
Shipping & Returns
Shipping & Returns
LPH-18-TFS - Mean Well LPH-18 Series Double Insulated Mains Input LED Driver 18W - 20W 12V – 36V
LPH-18-TFS - Mean Well LPH-18 Series Double Insulated Mains Input LED Driver 18W - 20W 12V – 36V
Constant VoltageFully encapsulated with IP67 levelProtections: Short circuit/ Overload/ Over voltage/ Over temperatureOther features: 180~264VACClass 2 power unitIsolation class II, no F.G.Cooling by free air convectionPass LPS100% full load burn-in testLow cost, High reliability2 years warranty
More Information Manufacturer Mean Well Output Wattage (W) 18 Dimmable (Type) No Dimensions 140 x 30 x 20 (LxWxH) Mm EMC Standards EN55022 class B, EN61000-3-2 class A, EN61000-3-3, EN61000-4-2, 3, 4, 5, 6, 8, 11 Input Voltage 180~264VAC Safety Standards TUV EN60950-1 approved, Design refer to UL1310, EN61347-2-13 Output Voltage Options Single Working Temperature -20~+70°C PDF Datasheet LPH-18TF_Series.pdf
More Information Manufacturer Mean Well Output Wattage (W) 18 Dimmable (Type) No Dimensions 140 x 30 x 20 (LxWxH) Mm EMC Standards EN55022 class B, EN61000-3-2 class A, EN61000-3-3, EN61000-4-2, 3, 4, 5, 6, 8, 11 Input Voltage 180~264VAC Safety Standards TUV EN60950-1 approved, Design refer to UL1310, EN61347-2-13 Output Voltage Options Single Working Temperature -20~+70°C PDF Datasheet LPH-18TF_Series.pdf
Select voltage
From $20.52
LPH-18-TFS - Mean Well LPH-18 Series Double Insulated Mains Input LED Driver 18W - 20W 12V – 36V—
$20.52
Product Information
Product Information
Shipping & Returns
Shipping & Returns
Description
Constant VoltageFully encapsulated with IP67 levelProtections: Short circuit/ Overload/ Over voltage/ Over temperatureOther features: 180~264VACClass 2 power unitIsolation class II, no F.G.Cooling by free air convectionPass LPS100% full load burn-in testLow cost, High reliability2 years warranty
More Information Manufacturer Mean Well Output Wattage (W) 18 Dimmable (Type) No Dimensions 140 x 30 x 20 (LxWxH) Mm EMC Standards EN55022 class B, EN61000-3-2 class A, EN61000-3-3, EN61000-4-2, 3, 4, 5, 6, 8, 11 Input Voltage 180~264VAC Safety Standards TUV EN60950-1 approved, Design refer to UL1310, EN61347-2-13 Output Voltage Options Single Working Temperature -20~+70°C PDF Datasheet LPH-18TF_Series.pdf
More Information Manufacturer Mean Well Output Wattage (W) 18 Dimmable (Type) No Dimensions 140 x 30 x 20 (LxWxH) Mm EMC Standards EN55022 class B, EN61000-3-2 class A, EN61000-3-3, EN61000-4-2, 3, 4, 5, 6, 8, 11 Input Voltage 180~264VAC Safety Standards TUV EN60950-1 approved, Design refer to UL1310, EN61347-2-13 Output Voltage Options Single Working Temperature -20~+70°C PDF Datasheet LPH-18TF_Series.pdf
